36) Temperature Gauge
Expedition TUV
The gauge indicates engine coolant
temperature. The needle moves to
the normal range as engine warms.
Under all riding conditions, the needle
should stay within this range. If nee-
dle moves into the overheat range,
reduce snowmobile speed and run
snowmobile in loose snow or stop
engine immediately.
A32A27A
2
1
TYPICAL
1. Normal
2. Overheat
37) Adjustable Mirrors
Each mirror can be adjusted to suit
driver's preference.
WARNING
Adjust with vehicle at rest in a safe
place.
WARNING
Objects in mirror are closer than
they appears.
38) Mechanical Fuel
Level Gauge
All Models except Expedition
TUV
Located at rear of fuel tank cap, the
gauge facilitates fuel level reading.
A32A25B
1 2
TYPICAL
1. Full
2. Empty
48
