All Other Models
To remove backrest, remove wing
screw on both sides.
mmo2008-001-021_a
1. Wing screw
All Models
CAUTION: Take care to store back-
rest properly to avoid any damages.
33) Rear Grab Handles/
Heated Grips Switch
Expedition TUV
mmo2007-001-018_a
TYPICAL
1. Left side passenger grab handle
2. Heated grips switch
Rear Grab Handles
Rear grab handles provides a grip for
the passenger.
Heated Grips Switch
Three-position switch. Select the de-
sired position to keep rear passenger's
hands at a comfortable temperature.
34) Tachometer
Direct-reading dial indicates the num-
ber of thousand of revolutions per
minute (RPM) of the engine.
A33E0AA
TYPICAL — MULTIPLY THE READING
BY 1000
35) Electric Fuel Level
Gauge
Expedition TUV
Dash-mounted gauge to facilitate fu-
el level reading. This gauge functions
when engine is running.
A32A26A
2
1
TYPICAL
1. Full
2. Empty
_____________________
47
