SKANDIC WT/SUV/SWT
MODEL
550F
STEERING SYSTEM
Ski type ADJ
Toe-out mm (in) 5 (.197)
Camber 0°
VEHICLE INFORMATIONS
WT kg lb 285 (628.3)
SWT kg lb 302 (665.8)Mass (dry)
SUV kg lb 300 (661.4)
WT m (in) 3.06 (120)
SWT m (in) 3.06 (120)Length
SUV m (in) 3.06 (120)
Width m (in) 1.08 (42.5)
Height m (in) 1.3 (51)
SUV mm (in) 985 (38.8)
Ski stance (carbide to carbide)
WT/SWT mm (in) 900 (35.4)
(1)
Measure gap between slider shoe and bottom inside of track when exerting a downward pull to the track.
(2)
Equal distance between edges of track guides
and slider shoes.
(3)
Drive belt height must be adjusted every time a new drive belt is installed. Confirm drive belt part number
application with an authorized SKI-DOO de
aler.
74
