SKANDIC WT
MODEL
600
DRIVE SYSTEM
Type XP-S synthetic chaincase oil
Gearbox oil
Quantity ml (U.S. oz) 500 (16.9)
1
st
1 : 2.82
2
nd
1 : 1.70
Gear ratio
R
1 : 3.44
Drive pulley type TRA III
Drive pulley calibration Clutch engagement 2700 ± 100 RPM
Driven pulley type 6-K VSA
Drive belt P/N 605 348 425
(3)
Width mm (in) 37.3 (1.469)
Drive belt
Wear limit mm (in) 35.8 (1.409)
Deflection mm (in) 40 to 50 (1.575 to 1.969)
Drive belt adjustment
Force kgf (lbf) 11.30 (24.91)
Width mm (in) 500 (20)
Length m (in) 3.968 (156)Track
Profile height mm (in) 31.8 (1.25)
Deflection
(1)
mm (in) 40 to 50 (1.575 to 1.969)
Force
(1)
kgf (lbf) 7.3 (16)Track adjustment
Alignment
(2)
BRAKE SYSTEM
Brake lining thickness Service limit mm (in) 1 (.039)
Type DOT 4
Brake fluid
Quantity ml (U.S. oz) 60 (2.0)
FRONT SUSPENSION
Suspension type LTS
Suspension maximum travel mm (in) 151 (6)
Shock absorber type Hydraulic
76
