Skyjack SJ12 User Manual

43
SJ12, SJ16 213721AAA
Function tests Section 4 – Inspections Before Operation
4.3-16 Do a test of the elevated travel
speed
WARNING
Look for overhead obstructions or other possible
hazards around the MEWP when you raise the
platform. Do not lower the platform unless the area
below is clear of personnel and obstructions. If
you do not obey, there is a risk of death or serious
injury.
1. Pull the emergency stop button
4
.
2. Make sure the path of intended motion is clear.
3. Raise the platform until it is at a height of
approximately 60 cm (2 ft).
4. Drive the MEWP forward and then rearward.
▪
Result: The MEWP drives slower than when it
was in the lowered travel position.
5
4
3
1
6
2

Skyjack SJ12 Specifications

General

Gradeability	25%
Drive Motor	24V DC
Machine Width	32 in (0.81 m)
Stowed Height	6.5 ft
Overall Width	32 in (0.81 m)
Stowed Height (Rails Folded)	6.5 ft
Drive Speed (Elevated)	0.5 mph (0.8 km/h)
Power Source	Electric
