Skyjack SJ12 User Manual

61
SJ12, SJ16 213721AAA
Specifications Section 7 – Specications
Model SJ12 SJ16
Weight * 863 kg (1905 Ib) 980 kg (2160 lb)
Overall Width 78 cm (30.5 in) 78 cm (30.5 in)
Overall Length 140 cm (55.2 in) 140 cm (55.2 in)
Platform Size (Inside)
68 cm x 85 cm
(27.0 in x 33.3 in)
68 cm x 85 cm
(27.0 in x 33.3 in)
Platform Traversing 41 cm (16 in) 41 cm (16 in)
Height
Working Height 5.5 m (18 ft) 6.6 m (21.7 ft)
Platform Elevated Height 3.66 m (12 ft) 4.78 m (15.7 ft)
Stowed Height 178.3 cm (70.2 in) 178.3 cm (70.2 in)
Drive Height Full Full
Lowered Platform Height 45.72 cm (18 in) 45.72 cm (18 in)
Standard Operating Times
Lift Time (Rated Load) 13 s - 16 s 16 s - 25 s
Lower Time (Rated Load) 13 s - 17 s 17 s - 19 s
Chassis
Normal Drive Speed
3.1 km/h - 4.0 km/h
(2.0 mph - 2.5 mph)
3.1 km/h - 4.0 km/h
(2.0 mph - 2.5 mph)
Elevated Drive Speed
0.6 km/h - 0.8 km/h
(0.4 mph - 0.5 mph)
0.6 km/h - 0.8 km/h
(0.4 mph - 0.5 mph)
Gradeability (Ramp Angle [Reverse/Forward])** 30% / 25% 30% / 25%
Tires (Solid Rubber) 309 mm x 100 mm (12 in x 4 in) 309 mm x 100 mm (12 in x 4 in)
Hydraulic Oil
Type ATF Dexron III ATF Dexron III
Tank Capacity 4.92 l (1.3 gal) 4.92 l (1.3 gal)
* Weights are approximate; refer to serial nameplate for specific weight.
** Refer to Section 6.4 Move the MEWP for Transport in the Operation manual for more details.
1835AA
7.3 Specications

Skyjack SJ12 Specifications

General

Gradeability	25%
Drive Motor	24V DC
Machine Width	32 in (0.81 m)
Stowed Height	6.5 ft
Overall Width	32 in (0.81 m)
Stowed Height (Rails Folded)	6.5 ft
Drive Speed (Elevated)	0.5 mph (0.8 km/h)
Power Source	Electric
