Section 3 - Operation Component Identification (Special Options)
3.6-7 Welder (If Equipped)
The welder is installed on the platform. Refer to
welder’s operating manual for proper operation and
maintenance.
1
2
Figure 3-8. Welder
1. Welder - This equipment is plugged into its
dedicated AC outlet on the platform.
2. Welder AC Outlet - This AC outlet is dedicated
for the welder.
NOTE
In sub-zero temperatures, the hydraulic oil
should be warmed, prior to operating the
welder.
NOTE
This option adds 90 lb. (41 kg) to the
platform. This weight must be included
when determining the total load on the
platform, including personnel and other
materials.
WARNING
Only qualied persons should install,
operate, maintain and repair the welder.
CAUTION
Breathing welding fumes and gases can
be hazardous to your health.
3.6-8 Arctic Weather Package (If Equipped)
The heater plug is located on the engine compartment
near the battery.
1
Figure 3-9. Heater Plug
1. Battery/Hydraulic Oil/Engine Oil Heater Plug -
This cord is plugged into the AC outlet at least 3
hours before starting engine when temperature
gets below -18°C (0°F).
SJ 40T & SJ 45T
SJ 61T & SJ 66T
Page 49
