No. Label Pictorial Description

Base Control Console

Push “ ” breaker back in to reset. Select and hold

“ ” to enable error blink code for engine control unit (ECU).

Read “” operating manual.

Push and hold “ ” to start engine, “ ” to enable the emergency

power unit or “ ” to enable base control functions.

Select “ ” to rotate platform to the left or “ ” to rotate to the right.

Select “ ” to tilt platform up or “ ” to tilt platform down.

Select “ ” to move jib up or “ ” to move jib down.

Select “ ” to rotate turret to the left or “ ” to rotate to the right.

Select “ ” to raise main boom or “ ” to lower main boom.

Select “ ” to extend y boom or “ ” to retract y boom.

Select “ ” to turn engine off, “ ” to enable base control console

or “ ” to enable platform control console.

Push “ ” emergency stop to stop engine and disable controls.

Control Compartment

SJ 40T & SJ 45T

SJ 61T & SJ 66T

Page 89

Section 5 Labels
