Section 5 – Procedures Skycoded Module
Skycoded Control Module Menu Table
Items highlighted in grey requires technician access level 2 to change. Otherwise, menus are locked as initial
factory access level 1.
Menu Selection Sub-Menu Description
HELP
LOGGED
HELP
HELP
Press ENTER when viewing the current HELP message to see a log of recent HELP messages
Press to see older messages, and to see newer ones
Press ESC to return to the current HELP message
LANGUAGE 0=ENGLISH
Press or select languge prefered on the display
DIAGNOSTICS
SYSTEM
MODE
OPERATING
MODE
Displays current operating mode or interlock
INTERLOCK
When current operating mode shows INTERLOCKED, press ENTER to see the reason for the interlock
Press ESC to return to the current operating mode
SUPPLY Displays battery supply voltage
VALVESUPPLY Displays valve supply state
MOTOR V Displays motor voltage
MOTOR I Displays motor current
TEMPERATURE Displays temperature (˚C)
TILT Displays tilt values (X˚, Y˚)
TILTED Displays whether system is in tilted mode (measured tilt exceeds tilt trip points)
HEIGHT
Displays platform height, calculated from angle, pressure transducers and data stored during calibration.
Angle transducers are installed, press ENTER when viewing the HEIGHT (which is the average of the two).
To see the individual measurements of the two sensors, named HEIGHT1 and HEIGHT2 (press and to
see both); press ESC to return to the average HEIGHT.
LOAD
Displays Platform load (estimated from lift cylinder pressure measurement, platform height, and height/pres-
sure curves stored during calibration).
OVERLOADED Displays whether system is in overload mode (Platform load exceeds load trip point, at/above overload height)
LAST MOVED
Displays whether the most recent Platform movement was UP or DOWN; this is important if the lift cylinder
pressure is affected by the direction of movement (during calibration, separate measurements are collected
during lifting and lowering)
ELEVATED Displays whether system is in elevated mode
AORcase Displays Anti Over-Rise state
TELElock Displays Telematics option
PLATFORM
TRIGGER Displays ON when Platform trigger pressed
DLD Displays drive / lift mode (from S3 Lift/Off/Drive switch)
JOYSTICK Displays joystick position (%)
FWD/UP Displays ON when joystick is moved toward FWD or UP
REV/DOWN Displays ON when joystick is moved toward REV or DOWN
LEFT Displays ON when steer left button pressed
RIGHT Displays ON when steer right button pressed
POSITRAC Displays ON when traction switch is pressed
EMSp Displays ON, indicating Platform Emerency Stop circuit is active
