Skycoded Module Section 5 – Procedures
Menu Selection Sub-Menu Description
GROUND
UP Displays ON when UP switch pressed
DOWN Displays ON when DOWN switch pressed
OUT Displays ON when (optional) deck out switch pressed
IN Displays ON when (optional) deck in switch pressed
EMSg Displays ON, indicating ground Base Emergency Stop is active
INPUT
P3-1 Shows P3-1 input status (S10 Idle/PLTF/Base Key switch active)
P3-2 Shows P3-2 input status (valve supply, on with Platform E-stop active)
P3-3 Shows P3-3 input status (S27 Torque switch select high torque)
P3-4 Shows P3-4 input status (S17 indoor/outdoor switch select indoor) (if equipped)
P3-5 Shows P3-5 input status (S10 Idle/PTLF/Base Key switch select Base)
P3-6 Shows P3-6 input status (S3 Lift/Off/Drive switch select Drive)
P3-7 Shows P3-7 input status (S3 Lift/Off/Drive switch select Lift)
P3-8 Shows P3-8 input status (S7-2 STEER RIGHT from joystick)
P3-9 Shows P3-9 input status (S7-2 STEER LEFT from joystick)
P3-10 Shows P3-10 input status (KC Anti Overrise N.O. signal)
P3-11 Shows P3-11 input status (KC Anti Overrise N.C. signal)
P3-12 Shows P3-12 input status (S7-6 Enable switch from joystick)
P4-1 Shows P4-1 input status (S51 Emergency Lowering Toggle counter)
P4-2 Shows P4-2 input status (not used)
P4-3 Shows P4-3 input status (not used)
P4-4 Shows P4-4 input status (S2 Lift/Lower Toggle switch DOWN select)
P4-5 Shows P4-5 input status (S2 Lift/Lower Toggle switch UP select)
P4-6 Shows P4-6 input status (not used))
P4-7 Shows P4-7 input status (LS1 & LS2 Pothole Protection limit sw’s active)
P4-8 Shows P4-8 input status (powerdeck extended) (if equipped)
P4-9 Shows P4-9 input status (powerdeck retracted) (if equipped)
P4-10 Shows P4-10 input status (charger cutout interlock switch)
P4-11 Shows P4-11 input status (not used)
P4-12 Shows P4-12 input status (not used)
JOYSTICK
INPUTS
Shows Joystick M3 input status CANBus (not used)
ANALOGS
P1-2 Displays voltage measurement of joystick analog input P1-2
P1-4 Displays Trackunit Telematics option (if equiped)
P2-2 Displays voltage measurement of AT1 Angle Transducer analog input P2-2 signal
P2-4 Displays voltage measurement of PT1 Pressure Transducer analog P2-4 signal
P2-5 Displays voltage measurement of AT Angle Transducer analog input P2-5 signal
Skycoded Control Module Menu Table (Continued)
