159
SJ3220, SJ3226, SJ4720, SJ4726, SJ4732 223198ABA
Skycoded Module Section 5 – Procedures
Menu Selection Sub-Menu Description
INTERLOCKS
(CONT.)
FUNCTIONhold
Only applicable if drive/lift mode is selected with momentary push switches; when using a drive/lift toggle
switch.
TELEMATICS Determines if the Telematics option is "Normal" or has a "Lockout" keypad option installed.
IDLE TIMEOUT
Determines time until Control Module CM1 goes into sleep mode if no functions or operations have been
requested for that time.
C LIMIT Determines the Current Limit of the motor before being derated. Set below the fuse amperage.
CALIBRATIONS (Access Level 1 required)
Temp
Factory set to calibrate heatsink temperature (motor power may be reduced if the heatsink temperature is too
high.
Current Factory set to calibrate motor current.
TiltGain
Factory set to calibrate Control Module CM1 tilt sensor.TiltXoff
TiltYoff
UserXoff
Set when the “CALIBRATE LEVEL” procedure is carried out, to correct for slight tilt offset due to mounting of
the Control Module CM1 to machine chassis, and chassis to ground.
UserYoff
Height1Min
Set when the “CALIBRATE HEIGHT” (or “CALIBRATE LOAD” dynamic) procedure is carried out, to determine
the Angle Transducers measurements when the platform is fully lowered (0% height) and fully raised (100%
height).
Height1Max
Height2Min
Height2Max
ElevUp
Set when the “CALIBRATE HEIGHT” (or “CALIBRATE LOAD” dynamic) procedure is carried out, to determine
the platform height.
ElevDown
OVERLOAD CALS
This sub-menu provides access to the load calibration data created during the “CALIBRATE LOAD” loaded &
empty procedure.
SERIAL NUMBER (Access level 2 required)
yy/mm/nnnnn Displays the Control Module CM1 serial number
Skycoded Control Module Menu Table (Continued)
Items highlighted in grey requires access level 2.
