Skyjack SJ51AJ Parts Manual

Articulating Boom Series
Models SJ46AJ & SJ51AJ
170947
SKYJACK, Page 101
4.21 Base Control Box - Deutz D2011, GM & Kubota (continued)
Index
No.
Skyjack
Part No.
Qty. Description
Parts list continued from the previous page.
20 138767 1 • WASHER, Internal tooth (7/8”, zinc)
21 144652 1 • SWITCH, Emergency stop red
147056 1 • • LATCH, Mounting
147053 1 • • BLOCK, NC Contact
147229 1 • • SWITCH, LED block
147051 1 • • SWITCH HEAD, Emergency stop
22 148971 1 • LIGHT, Pilot (Amber)
23 148972 1 • LIGHT, Pilot (Green), A, B, C, D
139127 1 • PLUG, Hole (1/2”), E, F
24 138278 3 • SWITCH, Toggle
25 146652 1 • HORN (12V)
26 126499 2 • SCREW, Round head machine (#8-32 x 7/8”), A, B, D, E, F
27 139127 1 • PLUG, Hole (1/2”), E, F
28 138725 1 ENGINE CONTROL UNIT, Deutz, A, B, C, D
196016 1 ENGINE CONTROL UNIT, GM, E
29 115649 9 NUT, Hex lock (1/4”-20 Grade 5, nylon), A, B, C, D
5 NUT, Hex lock (1/4”-20 Grade 5, nylon), E, F
30 103995 8 WASHER, Flat (1/4”), A, B, C, D
4 WASHER, Flat (1/4”), E, F
31 149056 1 BRACKET, Base control mounting
32 103473 3 BOLT, Hex head (3/8”-16 x 1”, Grade 5)
33 125959 3 WASHER, Flat hardened (3/8”)
34 195404 1 BACKPLATE, PASO controller, B
35 104698 2 SCREW, Round head machine (10-32 x 0.75”), B
36 103957 2 SCREW, Round head machine (8-32 x 0.50”), B
37 104694 2 WASHER, Flat (#10), B
38 300450 2 NUT, Hex head nylon lock (10-32), B
39 138765 2 NUT, Hex head nylon lock (8-32), B
40 164832 1 LIGHT, Indicator 12V (red), B
41 (Ref.) 1 POSITIVE AIR SHUT-OFF ASSEMBLY,
B
(For components, refer to Section 9.30)
42 114710 1 KEYRING
AE
