Skyjack SJ51AJ Parts Manual

Articulating Boom Series
Models SJ46AJ & SJ51AJ
170947
SKYJACK, Page 99
4.21 Base Control Box - Deutz D2011, GM & Kubota
Index
No.
Skyjack
Part No.
Qty. Description
A 163571 - BASE CONTROLS (46AJ ANSI/CSA - Deutz D2011)
B 195416 - BASE CONTROLS (46AJ ANSI/CSA - Deutz D2011 w/Positive Air Shut-Off)
C 163581 - BASE CONTROLS (46AJ/51AJ CE - Deutz D2011)
D 163611 - BASE CONTROLS (46AJ/51AJ AS - Deutz D2011)
E 163578 - BASE CONTROLS (46AJ ANSI/CSA - GM)
F 170412 - BASE CONTROLS (46AJ ANSI/CSA - Kubota)
1 149278 1 • CONTROL BOX, A, C, D, E, F
195371 1 • CONTROL BOX, B
149279 1 • • BODY, Control box
149281 1 • • HINGE, Steel
149280 1 • • DOOR, Control box
149282 1 • • WEATHER STRIP
149437 2 • • FASTENER, Door
149320 2 • • RETAINER, 1/4 Turn
149321 2 • • RECEPTACLE, 1/4 Turn
2 (Ref.) - • TERMINAL STRIP, Base
(For components, refer to Section 4.22)
3 127131 11 • RELAY, (12V 40 AMP), A
12 • RELAY, (12V 40 AMP), B, C, D
8 • RELAY, (12V 40 AMP), E, F
4 138749 14 • SOCKET, Automotive relay, A, B, C, D
11 • SOCKET, Automotive relay, E, F
5 104003 6 • NUT, Hex head (#10-32)
6 104694 6 • WASHER, Flat (#10)
7 149426 1 • ANGLE TRANSDUCER
8 103957 14 • SCREW, Round head machine (#8-32 x 1/2”), A, B, D, E, F
16 • SCREW, Round head machine (#8-32 x 1/2”), C
9 138765 16 • NUT, Hex lock (#8-32 Grade 5, nylon)
10 138751 3 • HOUSING, Open bottom 24 pin levered
11 138756 2 • SOCKET, 24 Pin spring (16A)
12 138755 1 • PLUG, 24 Pin spring (16A)
13 103056 1 • BEEPER (7.5 - 16 VDC), A, B, D, E, F
14 116266 4
• CONNECTOR, Heyco liquid tight
15 131938 1 • PLUG (1 1/8”)
16 117325 3 • CIRCUIT BREAKER (15 AMP)
17 102853 6 • SWITCH, Toggle, A, B, C, D
5 • SWITCH, Toggle, E, F
18 103336 1 • HOUR METER
19 138277 1 • KEYSWITCH (3-position), A, B, D, E, F
138137 1 • • KEY (#455)
138136 1 • • NUT, Key switch
144366 1 • KEYSWITCH (3-position), C
Parts list continued from the previous page.
