Skyjack SJ51AJ Parts Manual

Articulating Boom Series
Models SJ46AJ & SJ51AJ
170947
SKYJACK, Page 155
7.1 Deutz D2.9L Diesel Engine
Index
No.
Skyjack
Part No.
Qty. Description
- 167654 1 ENGINE ASSEMBLY - Deutz D2.9L (46AJ ANSI/CSA)
1 154084 1 • ENGINE, Diesel (Deutz D2.9L)
166689 1 • • CAP, Oil filler
166690 1 • • DIPSTICK
166691 1 • • PLUG, Oil pan drain
166692 1 • • STARTER, 3.2kW
166693 1 • • ALTERNATOR
166694 1 • • BELT, Alternator and water pump
164770 1 • • PUMP, Fuel
164771 1 • • FILTER, Fuel
164772 1 • • PRE-FILTER, Fuel
147072 1 • • FILTER, Oil
166695 1 • • GASKET SET
166696 1 • • PUMP, Coolant
166698 1 • • PLUG, Glow
166699 1 • • THERMOSTAT
166700 1 • • SENSOR, Fuel pressure
166701 1 • • SENSOR, Mag pick-up
166702 1 • • SENSOR, Coolant temperature
166703 1 • • SENSOR, Oil pressure
166704 1 • • SENSOR, Intake air pressure
164845 1 • • ECU
170956 1 • • COMPENSATOR
170957 1 • • CLIP, Compensator
170958 1 • • NUT, Compensator
170959 1 • • CLIP, Compensator
170960 1 • • CATALYST
170961 1 • • GASKET, Compensator
2 (Ref.) - • ENGINE COUPLING ASSEMBLY
(For components, refer to Section 7.8)
3 163047 1 • MOUNT, Front LH
163049 1 • MOUNT, Front RH
4 103469 4 • BOLT, Hex head (1/2”-13 x 3.25”, Grade 5)
5 163200 4 • WASHER, Snubbing, engine mount
6 149419 10 • BOLT, Hex head (M12 x 1.75” x 35mm, Grade 8.8)
7 112532 8 • BOLT, Hex head (5/16”-18 x 1.25”, Grade 5)
8 103996 16 • WASHER, Flat (5/16”)
9 163051 2 • MOUNT, Rear engine
10 163028 4 • MOUNT, Vibration - Deutz
11
103984 8 • NUT, Hex hylon lock (5/16”-18, Grade 5)
- 165038 1 • RADIATOR ASSEMBLY - D2.9L
12 160366 11” • • HOSE, Fuel Line (3/16”)
13 165058 1 • • SENSOR, Coolant level
Parts list continued from the previous page.
