Skyjack SJ51AJ Parts Manual

Articulating Boom Series
Models SJ46AJ & SJ51AJ
170947
SKYJACK, Page 157
7.1 Deutz D2.9L Diesel Engine (Continued)
AE
Index
No.
Skyjack
Part No.
Qty. Description
Parts list continued from the previous page.
14 166949 1 • • WASHER, Sealing (M16)
15 163395 1 • • GUARD, Fan
16 133222 1 • • CLAMP, Gear (SAE No. 32, 1-9/16” - 2-1/2”)
17 142415 2 • • CLAMP, Gear (SAE No. 20, 3/4” - 1-3/4”)
18 163228 1 • • KIT, Radiator - Deutz D2.9L
170934 1 • • • HOSE, Radiator - upper
170935 1 • • • HOSE, Radiator - lower
170951 1 • • • HOSE, Radiator - return
19 137241 2 • • WASHER, Fender (1/2” ID)
20 103470 2 • • WASHER, Lock (1/2”, Grade 5)
21 108818 2 • • BOLT, Hex head (1/2”-13 x 2.75”, Grade 5)
22 144129 2 • • CLIP, Single (S332G10)
23 102984 34” • • HOSE, Fuel line (5/16” ID)
24 104528 3 • • CLAMP, Gear (SAE No. 28, 1-5/16” - 2-1/4”)
25 166164 4 • • WASHER, Flat standard (5/16”)
26 133174 17 • • BOLT, Hex head (M8 x 1.25 x 20mm, Grade 5)
27 133232 13 • • WASHER, Flat (M8)
28 149496 6 • • NUT, Speed clip (1/4”-20 x 0.5L)
29 163226 1 • • RADIATOR, Deutz D2.9L
212384 1 • • • SHROUD, Fan
30 103321 5 • • CLAMP, Gear (SAE No. 4, 1/4” - 5/8“)
31 163227 1 • • RESERVOIR, Coolant, Degas TK - Deutz D2.9L
32 166737 3.75” • • HOSE, Fuel line (3/8” ID)
- 167655 1 • AIR INTAKE ASSEMBLY - Deutz D2.9L
33 163250 1 • • INDICATOR, Service
34 163247 1 • • CONNECTOR, 90° Service indicator E200
35 163242 1 • • CLEANER, Air E200
165947 1 • • • ELEMENT, Primary
165948 1 • • • ELEMENT, Secondary
36 163244 1 • • BRACKET, Air cleaner E200
37 163246 1 • • CONNECTOR, 90° E200
38 167657 1 • • PLATE, Shroud
39 137625 69” • • TRIM, Rubber
40
121869 4 • • CLAMP, Gear (2-5/8” - 3”)
41 103995 6 • • WASHER, Flat (1/4”)
42 104000 6 • • WASHER, Lock (1/4”)
43 103892 6 • • BOLT, Hex head (1/4”-20 x 0.625”, Grade 5)
44 103996 8 • • WASHER, Flat (5/16”)
45 103984 4 • • NUT, Hex head nylon lock (5/16”-18, Grade 5)
46 103632 1 • • BOLT, Hex head self tapping screw (1/4”-14 x 0.75”)
47 103858 2 • • BOLT, Hex head (1/4”-20 x 1.25”, Grade 8)
48 115649 2 • • NUT, Hex head nylon lock (1/4”-20, Grade 5)
49 103886 2 • • BOLT, Hex head (5/16”-18 x 1.50, Grade 5)
50 164893 1 • • TUBE, Air intake - Deutz D2.9L
Parts list continued from the previous page.
