Articulating Boom Series
Models SJ46AJ & SJ51AJ
170947
SKYJACK, Page 159
7.1 Deutz D2.9L Diesel Engine (Continued)
Index
No.
Skyjack
Part No.
Qty. Description
Parts list continued from the previous page.
51 123715 1 • • CLAMP, Clip
52 100616 2 • • GROMMET, Rubber (5/16” x 9/16” x 1/8”)
53 128571 2 • • SLEEVE, Anti-vibration mount
- 165072 1 • FAN INSTALL
54 163225 1 • • ADAPTER, Fan 14”
55 116218 4 • • WASHER, Lock (M8 plated)
56 139769 4 • • BOLT, Hex head (M8 x 1.25” x 45mm, Grade 8.8)
57 163224 1 • • FAN, 14” dia. - Deutz D2.9L
58 104000 4 • • WASHER, Lock (1/4”)
59 103856 4 • • BOLT, Hex head (1/4”-20 x 0.75”, Grade 5)
60 164925 1 • EXHAUST PIPE
61 165602 1 • CABLE, Alternator
62 104379 4 • WASHER, Flat hardened (0.50”)
63 702507 4 • NUT, Hex head nylon lock (1/2”-13 Grade 5)
64 144129 1 • CLIP, Single (S332G10)
65 165678 1 • CABLE ASSEMBLY (#2/0, 3/8” x 33” x 5/16” (03, 03))
66 165022 1 GLOW PLUG HARNESS ASSEMBLY
104698 1 • SCREW, Round head machine (#10-32 x 0.75”)
104694 2 • WASHER, Flat (#10)
300450 1 • NUT, Hex head (#10-32, grade 5)
117696 1 • BOOT, Terminal, #4 AWG
(Ref.) 1 • HARNESS ASSEMBLY, Glow plug
(For components, refer to Section 5.6)
To Next Page
