Skyjack SJ51AJ Parts Manual

Articulating Boom Series
Models SJ46AJ & SJ51AJ
170947
SKYJACK, Page 177
7.5 Radiator & Air Intake Assemblies - Kubota WG2503
Index
No.
Skyjack
Part No.
Qty. Description
- 168708 1 RADIATOR ASSEMBLY
1 168423 1 • RADIATOR, Kubota WG2503
2 169273 1 • GUARD, Fan
- 168424 1 • BRACKET KIT, Radiator
3 194635 1 • • HOSE, Lower
4 194636 1 • • HOSE, Upper
5 194637 2 • • ISOLATOR (46.4 mm x 51.21 mm, 0.50”-13))
6 194638 4 • • ISOLATOR (25 mm x 19 mm, M8-1.25)
7 147142 1 • RESERVOIR, Coolant
8 102984 35” • LINE, Fuel (0.3125”)
9 102984 12” • LINE, Fuel (0.3125”)
10 133222 2 • CLAMP, Hose (2.00”)
11 104528 2 • CLAMP, Hose (1.75”)
12 163521 3 • CLAMP, Hose (0.63”)
13 149495 3 • CLAMP, Tube (0.50”)
14 116218 11 • WASHER, Lock (M8)
15 133174 10 • BOLT, Hex head (M8-1.25 x 20 gr 8.8)
16 933655 3 • BOLT, Hex head (M8-1.25 x 25 gr 8.8
17 103901 2 • BOLT, Hex head (0.50”-13 x 2.50” gr 5)
18 103856 1 • BOLT, Hex head (0.25”-20 x 0.75” gr 5)
19 104379 2 • WASHER, Flat (0.50” SAE hardened)
20 166164 5 • WASHER, Flat (0.312” USS)
21 103995 2 • WASHER, Flat (0.0.25”)
22 103470 2 • WASHER, Lock (0.50” gr 5)
23 133232 4 • WASHER, Flat (M8)
24 933832 2 • WASHER, Flat (M8 - OD 16.0)
25 115649 1 • NUT, Hex head nylon lock (0.25”-20 gr 5)
26 149496 6 • NUT, Speed clip (0.25”-20 x 0.50”)
27 933696 2 • NUT, Hex head nylon lock (M8-1.25)
- 170812 1 AIR INTAKE ASSEMBLY
28 170814 1 • BAFFLE, Kubota
29 170813 1 • TRAY, Baffle plate
30 168990 1 • TUBE, Side port
31 170815 1 • BRACKET, Breather
32 164757 1 • BAND, Mounting - air cleaner
33 164760 1 • CLEANER, Air - EP100
195293 1 • • ELEMENT, Primary
195294 1 • • ELEMENT, Secondary
Parts list continued from the previous page.
