Skyjack SJ51AJ Parts Manual

Articulating Boom Series
Models SJ46AJ & SJ51AJ
170947
SKYJACK, Page 179
7.5 Radiator & Air Intake Assemblies - Kubota WG2503 (continued)
Index
No.
Skyjack
Part No.
Qty. Description
Parts list continued from the previous page.
34 170778 1 • HOSE, Intake - clean side
35 170777 1 • HOSE, Intake - dirty side
36 163250 1 • INDICATOR, Service
37 406292 1 • ADAPTER, Pipe nipple (451)
38 103892 6 • BOLT, Hex head (0.25”-20 x 0.625” gr 5)
39 103858 2 • BOLT, Hex head (0.25”-20 x 1.25” gr 5)
40 103909 2 • BOLT, Hex head (0.50”-13 x 1.25” gr 5)
41 100616 2 • GROMMET, Rubber (0.3125” x 0.5625” x 0.125”)
42 115649 2 • NUT, Hex head nylon lock (0.25”-20 gr 5)
43 702507 2 • NUT, Hex head nylon lock (0.50”-13 gr 5)
44 103995 4 • WASHER, Flat (0.25”)
45 128571 2 • SLEEVE, Anti-vibration
46 139094 1 • FITTING, 90° elbow (0.125” NPTM - 0.125” NPTF)
47 121869 3 • CLAMP, Hose (2.50”)
48 137625 42” • TRIM, Rubber
49 103995 6 • WASHER, Flat (0.25”)
50 103468 2 • WASHER, Flat (0.50” SAE)
51 112532 2 • BOLT, Hex head (0.312”-18 x 1.25” gr 5)
52 166164 2 • WASHER, Flat (0.312” USS)
53 103984 2 • NUT, Hex head nylon lock (0.313”-18 gr 5)
