Articulating Boom Series
Models SJ46AJ & SJ51AJ
170947
SKYJACK, Page 255
9.25 Welder Option
Index
No.
Skyjack
Part No.
Qty. Description
A 148383 1 WELDER ASSEMBLY (46AJ ANSI/CSA)
1 138811 1 • WELDER (275A)
138813 1 • CABLE, Electrode (14’)
144376 1 • • ELECTRODE HOLDER (400A)
144573 168” • • CABLE
138814 1 • CABLE, Work (14’)
144377 1 • • GROUND CLAMP (400A)
144573 168” • • CABLE
144374 1 • PLUG, Locking (50A / 250V / 3P)
144603 2 • CLAMP, Cushioned loop (0.875” diameter)
L1 147112 2 • LABEL, Welder weight (90 lbs)
- 159917 1 MOUNTING ASSEMBLY, 12kW Welder
B 159948 1 • WELDER TRAY ASSEMBLY
2 159955 1 • • TRAY, Welder
3 137814 1 • • PLATE, Strap
4 103020 1 • • STRAPS (pair)
5 103855 2 • • BOLT, Hex head (1/4”-20 x 0.50”, Grade 5)
6 104000 2 • • WASHER, Lock (1/4”)
L1 147112 1 • • LABEL, Welder weight pictorial
C 144218 1 • BRACKET ASSEMBLY
7 144220 1 • • BRACKET, Welding cables
8 144219 2 • • U BOLT, Welder bracket
9 115649 4 • • NUT, Hex lock (1/4”-20 Grade 5, nylon)
10 103995 4 • • WASHER, Flat (1/4”)
D 144221 1 • RECEPTACLE ASSEMBLY
11 144222 1 • • PLATE, Receptacle mounting
12 144223 2 • • U BOLT, Receptacle mounting
13 141614 1 • • ELECTRICAL COMPONENTS ASSEMBLY
139835 1 • • • FD BOX, 50A Receptacle
139832 1 • • • RECEPTACLE, Single locking
139836 1 • • • COVER, Weather resistant
144367 1 • • • STRAIN RELIEF, 1-18” straight
14 115649 4 • • NUT, Hex lock (1/4”-20 Grade 5, nylon)
15 103995 4 • • WASHER, Flat (1/4”)
16 300450 5
• • NUT, Hex lock (#10-32 Grade 5, nylon)
17 105621 2 • • SCREW, Round head machine (#10-32 x 1”)
18 104694 2 • • WASHER, Flat (#10)
Parts list continued on the next page.
