Articulating Boom Series
Models SJ46AJ & SJ51AJ
170947
SKYJACK, Page 257
9.25 Welder Option (continued)
Index
No.
Skyjack
Part No.
Qty. Description
Parts list continued on the next page.
E 168530 1 • HANGER ASSEMBLY
19 169160 2 • • BRACKET, Welder cable
20 159947 2 • • SPACER, Welder tray
21 103866 2 • • BOLT, Hex head (5/16”-18 x 2 1/4 Grade 5)
22 103996 4 • • WASHER, Flat (5/16”)
23 103984 2 • • NUT, Hex lock nylon lock (5/16”-18 Grade 5)
24 124548 1 • • PIN, Quick release
25 103996 8 • WASHER, Flat (5/16”)
26 103884 4 • BOLT, Hex head (5/16”-18 x 2.50”, Grade 5)
27 103984 4 • NUT, Hex head nylon lock (5/16”-18, Grade 5)
28 103995 4 • WASHER, Flat (1/4”)
29 103857 4 • BOLT, Hex head (1/4”-20 x 1.00” Grade 5)
30 159960 2 • SPACER, Nylon (0.403” ID x 0.75” OD, x 0.312” long) (drop bar entrance)
168336 2 • SPACER, Nylon (0.394” ID x 0.75” OD, x 0.125” long)
AB
To Next Page
