Skyjack SJ51AJ Parts Manual

Articulating Boom Series
Models SJ46AJ & SJ51AJ
170947
SKYJACK, Page 59
4.1 Turret Assembly
AE
Index
No.
Skyjack
Part No.
Qty. Description
A 210262 1 TURRET ASSEMBLY - serial number 95 002 085 & above
B 168154 1 TURRET ASSEMBLY - serial number 95 002 084 & below
1 210263 1 • WELDMENT, Turret, A
162289 1 • WELDMENT, Turret, B
2 162290 1 • PLATE, Turret - upper left
3 162291 1 • PLATE, Turret - upper right
4 162292 2 • PLATE, Stiffener - turret
5 162293 2 • PAD, Guide (5.00” x 2.00” x 0.625”)
6 162294 1 • BRACKET, Bumper - lower cowling
7 159483 1 • PIN, Transportation locking
8 116494 2 • BUMPER, Engine guard
9 103472 25 • WASHER, Lock (3/8”)
10 103473 15 • BOLT, Hex head (3/8”-16 x 1” Grade 5)
11 700782 23 • WASHER, Flat hardened (5/8”)
12 103895 6 • BOLT, Hex head (5/8”-11 x 3” Grade 8), A
100844 6 • BOLT, Hex head (5/8”-11 x 2 3/4” Grade 8), B
13 103895 15 • BOLT, Hex head (5/8”-11 x 3” Grade 8), A
100844 15 • BOLT, Hex head (5/8”-11 x 2 3/4” Grade 8), B
14 103895 2 • BOLT, Hex head (5/8”-11 x 3” Grade 8), A
100844 2 • BOLT, Hex head (5/8”-11 x 2 3/4” Grade 8), B
15 103907 4 • BOLT, Hex head (1/2”-13 x 1.5” Grade 5)
16 103468 5 • WASHER, Flat (1/2” SAE AA)
17 117430 2 • BOLT, Hex head (3/8”-16 x 1.25” Grade 8)
18 104606 4 • NUT, Hex head nylon lock (3/8”-16 Grade 5)
19 101297 4 • BOLT, Hex head (3/8”-16 x 1 1/4” Grade 5)
20 103910 1 • BOLT, Hex head (1/2”-13 x 1.25” Grade 8)
21 103897 1 • BOLT, Hex head (5/8”-11 x 2” Grade 5)
22 103981 1 • NUT, Hex head (5/8”-11 Grade 5)
23 103856 1 • BOLT, Hex head (1/4”-20 x 0.75” Grade 5)
24 115649 1 • NUT, Hex head nylon lock (1/4”-20 Grade 5)
25 167459
19 • INSERT, 3/8”-16 AK series (0.150”-0.312”)
26 167460 7 • INSERT, 3/8”-16 AK series (0.027”-0.150”)
27 211208 1 • BRACKET, Limit switch, A
28 162293 1 PAD, Guide (5.00” x 2.00” x 0.625”)
29 101297 2 BOLT, Hex head (0.375”-16 x 1.25” Grade 5)
30 103472 2 WASHER, Flat (0.375”)
31 144238 2 NUT, Torque lock (0.375”-16 Grade C)
32 168619 1 SHROUD, Upper (46AJ)
168623 1 SHROUD, Upper (51AJ)
33 168622 1 SHROUD, Lower (46AJ)
168624 1 SHROUD, Lower (51AJ)
Parts list continued on the next page.
