Skyjack SJ51AJ Parts Manual

Articulating Boom Series
Models SJ46AJ & SJ51AJ
170947
SKYJACK, Page 61
4.1 Turret Assembly
AE
Index
No.
Skyjack
Part No.
Qty. Description
Parts list continued from the previous page.
34 137625 62” SEAL, Bulb (46AJ)
137625 58” SEAL, Bulb (51AJ)
35 101632 4 BOLT, Hex head (0.375”-16 x 0.75” Grade 5)
36 103472 4 WASHER, Flat (0.375”) (ANSI/CSA & AS)
127067 4 WASHER, Flat BB style (0.375”) (CE)
- 210399 1 DIRECTION SENSING LIMIT SWITCH ASSEMBLY, A
37 199486 1 • SWITCH, Limit - roller plunger (5 m), A
38 211213 1 • PLATE, Limit switch - threaded, A
39 126499 2 • SCREW, Round head machine (8-32 x 0.875”), A
40 208815 1 • RING, Protector - plastic, A
41 122249 2 • WASHER, Lock (#8), A
42 212110 1 PLATE, Cover, A
43 101297 4 BOLT, Hex head (0.375”-16 x 1.25” gr 5), A
44 103472 8 WASHER, Flat (0.375”), A

Skyjack SJ51AJ Specifications

General

Brand	Skyjack
Model	SJ51AJ
Category	Boom Lifts
Language	English
