Section 3 – Familiarization Component Identification
FAMILIARIZATION
Control Functions
Section 3.3
Manual Storage Box (behind seat)
Section 3.2
Operator’s Cab
Section 3.4-3
Frame Level
Cylitnder
Section 4.2-4
Wheel/Tire Assembly,
Drive Axle
Section 4.2-6
Mirrors
Section 4.2-5
Boom Lift Cylinders
Section 4.2-4
Boom Extension
Cylinder
Section 4.2-4
Engine Compartment
Section 4.2-7
Boom
Section 4.2-9
Fork/Lifting Attachment
Section 4.2-10
3.1 Component Identication
