SJ643 TH & SJ843 TH 216201ADA
51
Function Tests Section 4 – Pre-operation
P
N
FWD
REV
4.3-10 Test Parking Brake
WARNING
The seat belt must be worn at all times.
1. Ensure telehandler is on a rm, level surface.
2. Ensure the path of intended travel is clear
and area around telehandler is clear of any
personnel or obstructions.
3. Depress service brake, move parking brake
switch
1
to off position.
▪
Result: Parking brake indicator light should
turn off.
4. Move transmission lever to FWD (1st gear, for
powershift transmission), and gradually release
the service brake pedal.
▪
Result: Telehandler should roll forward.
5. Move parking brake switch to on position.
▪
Result: Parking brake should engage,
telehandler should stop immediately (less than
two seconds), and parking brake indicator
light should illuminate.
12
