Section 6 – Additional Procedures Lifting Skyjack SJ643 TH & SJ843 TH
6.2 Lifting Skyjack SJ643 TH
& SJ843 TH
1. Fully retract and lower boom.
2. Turn ignition switch to the off position.
Remove the key.
3. Block the rear axle by placing wood between the
frame and the axle.
WARNING
Use rigging with load capacity sufcient to
withstand telehandler weight. Refer to the serial
plate of the telehandler for specic weight.
4. Properly adjust rigging to ensure telehandler
remains level during lifting. See Center of gravity
location.
Figure 55 Center of gravity
Figure 56 Lifting points
Lifting Point
Lifting Point
SJ843 TH
SJ643 TH
80.2’’
71.5"
