Skyjack SJ643 TH - 13 Operators Cab Controls

SJ643 TH & SJ843 TH 216201ADA
45
Visual & Daily Maintenance Inspections Section 4 – Pre-operation
4.2-13 Operator’s Cab Controls
WARNING
Ensure that you maintain three points of contact to
enter/exit the cab.
▪
Use the steps of telehandler to access operator’s
cab.
▪
Ensure door and windows (if equipped) are
secure and in proper working order.
▪
Ensure operator’s cab controls
1
(refer to
Section 3.3-1) are secured with no sign of visible
damage.
▪
Ensure multi-function joystick
2
(refer to
Section 3.3-2 or Section 3.3-3) is secured,
movements are not obstructed and, with no sign
of visible damage.
▪
Ensure operator’s dash controls (refer to
Section 3.3-4)
3
are properly secured, returned
to their neutral position, with no sign of visible
damage.
▪
Ensure capacity charts
4
are in place and are
legible.
WARNING
Do not operate the telehandler if capacity charts
are missing or not legible.
1
3
1 1
1
4
2
3
