SECTION 6, Page 83
SJKB-40-D,SJKB-40-D/F
JUN. 1999
Index
No.
Skyjack
Part No.
Description
1 2 3 4 5 6 7
Units
per
Assy.
FIGURE 6-42. STEER AXLE ASSEMBLY (Optional 4x4)
706193 AXLE ASSEMBLY, Steer -
1 $ • NUT, Pinion retaining 1
2 $ • OIL SEAL, Pinion 1
3 $ • SEAL, O-ring 1
4 $ • WASHER, Oil plug 5
5 $ • COVER, Dust 2
6 $ • ACTUATOR, Brake 2
7 $ • BRAKE DISK, Intermediate 6
8 $ • BRAKE DISK, Friction 10
9 $ • SHAFT ASSEMBLY, Axle 2
$ • • JOINT, Universal 4
10 $ • SEAL, O-ring 2
11 $ • SEAL, Oil 4
12 $ • SEAL, Shaft 2
13 $ • SEAL, Shaft 2
14 708441 • CYLINDER ASSEMBLY, Steer 1
708408 • • KIT, Seal repair AR
15 $ • JOINT, Axial 2
16 $ • TIE ROD END 2
17 $ • NUT, Steer arm 2
18 (Ref.) • BRAKE ASSEMBLY (For components, refer to Figure 6-46.) 2
$ Consult factory
