SECTION 3, Page 4
SJKB-40-D, SJKB-40-D/F
JUN. 1999
Table 3-3. Relay Schedule
Mt40-300
RELAY NUMBER RELAY FUNCTION WIRES LOCATION ENGINE
01CR Engine Cutout Relay 01,02,09,01A,54 Base Panel All
08CR1 Start Dissalbe Relay 08,02,57,57A Platform Console All
08CR2 Drive Enable Relay 08,02,62C,62B Platform Console All
08CR3 Foot Switch Brake Relay 08,02,28,28A Base Panel All
108CR Emergency Pump Contactor 108,02,03,108A Base Panel All
11CR Fuel Select/Glow Plug
11,02,77,50,56/
11,02,54,11A
Engine Panel All
17CR1 Steer Directional Relay 17,02,23A,24,24A Base Panel All
17CR2 Steer Directional Relay 17,02,23,23A,24A Base Panel All
17CR3 Drive Directional Relay 17,02,61,62A Base Panel All
17CR4 Drive Directional Relay 17,02,62A,62B Base Panel All
20ACR Boom Control Relay 20A,02,10,10A Base Panel All
20CR Function Select Relay 20,02,20A,09 Base Panel All
21CR1 Dump Valve Relay 21,02,21A,09 Base Panel All
21CR2 Emergency Pump Relay 21,02,01A,108 Base Panel All
26ACR Brake Relay 02,09,26A,26B Base Panel All
28ACR Tilted Braking Relay 02,09,28A,28B Base Panel All
28CR Tilted Function Dissable Relay 28,02,08,99 Platform Console All
30ACR Level Circuit Interlock Relay 30A,02,10,47 Base Panel All
30BCR Level Circuit Interlock Relay 30B,02,08,08A Platform Console All
49CR Horn Option Relay 49,02,09,49A Base Panel Option
51CR1 Tilted Drive Cutout 51,02,62,62A Base Panel All
51CR2 Brake Feed Relay 51,26,26A,02 Base Panel All
54CR Engine Shutdown Relay 54,02,76,77,54C Engine Panel All
57ACR Starter Relay 57A,02,03,03A Engine Panel All
60ACR Base Panel Power Relay 60A,02,07,09 Base Panel All
74CR Choke Relay 74,02,54,74A Base Panel All
114CR Steering Bypass Relay 114,114A,09,02 Base Panel All
