Table 3-4. Wire Number and Color Code
WIRE
NO.
WIRE
COLOR
WIRE
NO.
WIRE
COLOR
WIRE
NO.
WIRE
COLOR
WIRE
NO.
WIRE
COLOR
WIRE
NO.
WIRE
COLOR
1 PUR/BLK 20 ORG/BLU 39 BLK/RED 64 WHT/BRN 93 BLK SHLD
2 WHT 21 WHT/RED 40 BLU/RED 68 GREY 94 YEL/GREY
3 GRN/PUR 22 PUR/GRN 41 BLU/PUR 69 WHT/GRN 96
WHT/GR-
EY
4 RED/YEL 23 BLK/WHT 46 RED/BLK 74 GRN/GREY 97 ORG/GREY
5 PUR 24 BLU/BLK 47 PUR/ORG 75 GREY/PUR 98 RED SHLD
6 25 BRN/BLK 48 YEL/GREY 76 BRN/BLU 98A BLK SHLD
7 RED 26 BLU/YEL 49 GRN/RED 77 BRN/GREY 99 BLK/GREY
8 PUR/WHT 27
RED/BLK/
WHT
50 BRN 78 RED/BLU 103 BLK/PUR
9 YEL 28 GRN 51 BLK/GRN 79 BRN/PUR 107 BLK/BLU
10 BLU/WHT 29 GREY/ORG 53 BRN/RED 80 GREY/WHT 108 YEL/BRN
11 WHT/ORG 30 RED/GRN 54 PUR/RED 81 GREY/BLK 109 GRN/YEL
12 GREY/ORG 31 RED/WHT 55 YEL/PUR 82 BRN/WHT 110A BLU
13 ORG 32 GRN/BLK 56 YEL/BLK 83 BLU/GREY 110B BRN
14 BLK 33 GRN/WHT 57 BRN/GRN 84
WHT/BLK/
PUR
111 GREY/GRN
15 BLU 34 ORG/BLK 59 YEL/BLU 85 GREY/BLU 114 YEL/RED
16 WHT/BLK 35 ORG/WHT 60 WHT/BLU 88 BLK/GRN 115 WHT/PUR
17 BLU/GRN 36 RED/PUR 61 GREY/BRN 90 RED/GREY 118 PUR/ORG
18 GRN/BLU 37
WHT/RED/
BLK
62 GREY/RED 91 RED SHLD
19 ORG/GRN 38 ORG/RED 63 GREY/YEL 92 GRN SHLD
MT40-301
This table is to be used as a wire number/color reference for all electrical drawings and schematics. All wire numbers
will retain their origional color coding, for example if wire 7 is red, wire 7A, 7B, and 7C will also be red.
