Skyjack SJKB-40-D - Page 29

SECTION 3, Page 6
SJKB-40-D, SJKB-40-D/F
JUN. 1999
1 701930 TOGGLE SWITCH, SPDT 2 position maintained AR
2 701929 TOGGLE SWITCH, SPDT 2 position momentary AR
3 701931 IGNITION SWITCH, Rotary 1
4 (Ref.) SWITCH ASSEMBLY, Emergency stop 1
102769 • SWITCH HEAD, Emergency stop 1
103281 • CONTACT BASE, NC switch 1
5 702662 TOGGLE SWITCH, DPDT 3 position momentary 3
6 102853 TOGGLE SWITCH, SPDT 3 position momentary 4
7 (Ref.) LIGHT ASSEMBLY, Indicator 3
103202 • LIGHT HEAD 1
102671 • LIGHT BASE 1
703185 • • BULB 1
8 702262 PLUG, 1/2” Knockout 2
9 707177 POTENTIOMETER 1
707253 • KNOB, Potentiometer 1
10 704330 CONTROLLER ASSEMBLY, Drive (without horn) 1
707658 CONTROLLER ASSEMBLY, Drive (with horn) 1
11 704332 CONTROL BOARD, Boom function 1
12 701943 RELAY, 12 Volt sealed 3
13 103057 BEEPER, 4-28 Volt alarm 1
14 103036 STRAIN RELIEF, Plastic 1
15 702186 WIRE DUCT, 1-1/2” 20”
707187 COVER, Wire duct 20”
16 707143 TERMINAL BLOCK, Through 16
17 707144 TERMINAL BLOCK, Ground 2
18 707146 END PLATE, Terminal block 1
19 707147 END STOP, Terminal block 2
20 707148 JUMPER, Terminal block 1
21 707149 DIN RAIL, Terminal .18
22 707145 TERMINAL BLOCK, Diode 2
23 700187 FOOT SWITCH 1
24 707875 RECEPTACLE, 40 Pin connector 1
707847 • GASKET, Connector 1
705258 • PIN, Contact 36
707822 • • TOOL, Pin removal AR
707823 • • TOOL, Crimp AR
25 102921 DIODE, 6 Amp/1000PIV 1
FIGURE 3-1./FIGURE 3-2. OPERATOR’S CONTROL CONSOLE DIAGRAM PARTS LIST
Index
No.
Skyjack
Part No.
Description
1 2 3 4 5 6 7
Units
per
Assy.
