Skyjack SJKB-40-D - Page 34

SECTION 3, Page 11SJKB-40-D, SJKB-40-D/F
JUN. 1999
FIGURE 3-3/FIGURE 3-4. BASE ELECTRICAL/CONTROL PANEL DIAGRAM PARTS LIST
Index
No.
Skyjack
Part No.
Description
1 2 3 4 5 6 7
Units
per
Assy.
1 707144 TERMINAL BLOCK, Ground 6
2 707143 TERMINAL BLOCK, Through 61
3 707145 TERMINAL BLOCK, Diode 22
4 707148 JUMPER, Terminal block 5
5 707149 DIN RAIL, Terminal 20”
6 707147 END BLOCK, Terminal block 2
7 707146 END PLATE, Terminal block 1
8 701943 RELAY, 12 Volt sealed AR
9 701547 CARD, Multi purpose controller (EDA) 1
• FUSE, 250 Volt, 3 amp
10 701546 CARD, Dual solenoid driver (MDSD) 1
• FUSE, 125 Volt, 4 amp
11 102853 SWITCH, Toggle 3 position momentary 7
12 701929 SWITCH, Toggle 2 position momentary AR
13 (Ref.) SWITCH ASSEMBLY, Emergency stop 1
102769 • HEAD, Emergency stop switch 1
103281 • BASE, N.C. Contact 1
14 (Ref.) SWITCH ASSEMBLY, Key 1
102753 • HEAD, Key switch 1
104466 • Key, #455 1
103279 • BASE, Contact 2 N.C. 1
103141 • CONTACT, N.O. AR
15 701931 SWITCH, Ignition 1
16 706282 GAUGE, Fuel 1
17 704732 VOLTMETER 1
18 701925 METER, Hour 1
19 105271 PLUG, Recessed male 110 volt 1
113227 • BOOT, Rubber 1
20 702402 BREAKER, 15 Amp circuit 2
21 102921 DIODE, 6 Amp/1000PIV 5
22 706074 SNAP-ON FERRITE CORE 1
23 707722 WIRE HARNESS, Main manifold 1
24 707709 WIRE HARNESS, Governor (All Kubota Engines) 1
708958 WIRE HARNESS, Governor (All Ford Engines) 1
25 707708 WIRE HARNESS, Engine control 1
700165 • CABLE, 20 Ga. shielded 180”
26 703720 LIGHT, Indicator amber (diesel only) 1
27 704677 CONTROL CABLE, 18/30 660”
28 105269 CABLE, 14/3 732”
29 706294 LIMIT SWITCH, Booted 1
30 700160 LIMIT SWITCH 1
31 702434 LIMIT SWITCH ASSEMBLY 1
32 700552 TILT SWITCH 1
33 704716 BRAKE MANIFOLD 1
34 702262 PLUG, 1/2” Knockout (All Ford Engines) 1
