Skyjack SJKB-40-D - Page 35

SECTION 3, Page 12
SJKB-40-D, SJKB-40-D/F
JUN. 1999
1 707708 WIRE HARNESS, Engine control 1
700165 • CABLE, 20 Ga. shielded 180”
2 708332 VALVE, High torque 1
708331 • COIL, 12 Volt 1
3 300242 CONTACTOR, Emergency pump 1
4 112838 PRESSURE SENSOR, Oil 1
5 708392 TEMPERATURE SENSOR, Coolant 1
6 111623 DIAPHRAM SWITCH, Vaccum 1
7 103011 TERMINAL BLOCK, Large 1
8 102921 DIODE, 6 Amp/1000 PIV 1
9 701943 RELAY, 12 Volt sealed 4
10 707824 TACHOMETER SENSOR 1
11 104345 CONNECTOR, Directional valve 2
12 707677 THROTTLE ACTUATOR, Linear 1
13 115329 ALTERNATOR 1
14 707676 CHOKE ACTUATOR, Linear 1
15 COIL, Ignition 1
16 115309 STARTER 1
FIGURE 3-5. ENGINE WIRING DIAGRAM PARTS LIST (Kubota Gas and Dual Fuel)
Index
No.
Skyjack
Part No.
Description
1 2 3 4 5 6 7
Units
per
Assy.
OCT. 1999
