SECTION 3, Page 15SJKB-40-D, SJKB-40-D/F JUN. 1999
Index
No.
Skyjack
Part No.
Description
1 2 3 4 5 6 7
Units
per
Assy.
FIGURE 3-6. ENGINE WIRING DIAGRAM PARTS LIST (Diesel)
1 707708 WIRE HARNESS, Engine control 1
700165 • CABLE, 20 Ga. shielded 180”
2 708332 VALVE, High torque 1
708331 • COIL, 12 Volt 1
3 300242 CONTACTOR, Emergency pump 1
4 102838 PRESSURE SENSOR, Oil 1
5 TEMPERATURE SENSOR, Coolant 1
6 103011 TERMINAL BLOCK, Large 1
7 102921 DIODE, 6 Amp/1000 PIV 1
8 701943 RELAY, 12 Volt sealed 3
9 707824 TACHOMETER SENSOR 1
10 104345 CONNECTOR, Directional valve 2
11 707675 THROTTLE ACTUATOR, Linear 1
12 115329 ALTERNATOR 1
13 115457 STARTER 1
