Initial Commissioning SMA Solar Technology AG
56 SI5048-TEN093630 Technical Description
– "New System" (if you would like to start a new system or perform changes to the system
configuration)
– "New Battery" (if you wish to reset battery-specific parameters only. You cannot change
general parameters using "New Battery")
– "Emerg Charge" (if you would like to charge a deeply discharged battery using an
external source)
3. Use "New System" to set the following parameters:
– Device type (master, slave 1, slave 2, slave 3)
–Voltage/frequency type (230V_50Hz, 220V_60Hz), default setting is "230V_50Hz"
– System configuration (see table for setting options), preset to "1Phase1".
– date / time
– Battery type (VRLA, FLA, NiCd), default setting is "VRLA"
– Nominal voltage of the battery (42 V - 52 V in 2-V steps for FLA and VRLA, 43.2 V to 48 V
in 1.2-V steps for NiCd), default setting: "48.0 V"
– Nominal battery capacity (100 Ah - 10000 Ah), default setting: "100 Ah"
Systems with one Sunny Island
If only one Sunny Island is used in the system, the device type is set to "master" and is not
displayed.
Displayed text Description
3Phase Three-phase system, 3 Sunny Islands
1Phase1 Single-phase system, 1 Sunny Islands
1Phase2 Single-phase system, 2 Sunny Islands
1Phase3 Single-phase system, 3 Sunny Islands
1Phase4 Single-phase system, 4 Sunny Islands
MC-Box Setting for multicluster operation
Battery types
VRLA: Valve Regulated Lead Acid
Closed lead acid batteries with immobilized electrolyte in gel or AGM (Absorbent Glass
Mat Separator) in all standard designs available on the market (grid plate, tubular plate,
small, large, AGM, Gel, etc.)
FLA: Flooded Lead Acid
Closed lead acid batteries with liquid electrolyte in all standard designs available on the
market (grid plate, tubular plate, small, large, etc.)
NiCd: Nickel-Cadmium
Pocket-type plate or fiber plate closed nickel cadmium batteries
