SMA Solar Technology AG Archiving Data on an SD Card
Technical Description SI5048-TEN093630 81
The files on the SD card have the following meanings:
The Sunny Island's firmware expects device-specific data in the main directory of the SD card.
This data includes a new firmware, parameters and measuring data.
The Sunny Island uses the SD card for saving and loading device parameters.
In addition, the Sunny Island supports the acquisition of measurement data on the SD card. It saves
this data in a special file. This contains, among other things, a header, time stamp, date and data type.
There are two different types of log data:
• Measurement data (is saved cyclically)
• Events and errors (are only saved when they occur)
The Sunny Island supports the acquisition of measurement data with data from the fields:
•Battery
•Inverter
•System
•External source
•Loads
File name Purpose
evthism.log (evthisN.log for slaveN) Event history of the device, saved by means of parameter
"550.03 CardFunc",
option StoEvtHis
failhism.log (failhisN.log for slaveN) Failure history of the device, saved by means of
parameter "550.03 CardFunc", option StoFailHis
si030607.evt Event/failure history for the day
(format: ddmmyy)
si030607.log Data recording for the day
(format: ddmmyy)
sipar1.lst parameter list of the device, created by means of
parameter "550.01 ParaSto", option Set1
sipar2.lst parameter list of the device, created by means of
parameter "550.01 ParaSto", option Set2
sipar.lst This file is saved after changing a parameter.
update.bin Software for the device
batstat.txt Statistical values of the battery. These values are saved
every day at 22:00 hours.
batstat.sma Internal data from SMA Solar Technology
si.ccf System information from Sunny Island
"BOOTEX.LOG" File
The "BOOTEX.LOG" file is not necessarily on the card. It is created depending on the
operating system used (e.g. WindowsXP or Windows2000).
