SmartDrive Systems SR4 Maintenance Guide

Copyright © 2018 SmartDrive Systems, Inc. All rights reserved. This information is intended for the use of SmartDrive 11
customers only. Any other use without the express written consent of SmartDrive Systems, Inc. is strictly prohibited.
SmartRecorder™ 4 Troubleshooting Guide
Analog Cameras.
 Analog Camera Feed Connections –
o If the Analog Camera is not connected to any other sources (ex – Monitor/Display
Screen); the Analog Camera will require an E1 cable (104-0002-0040-00) to provide
video feed to the SR4.
o If the Analog camera is connected to another source like a Backup Monitor the T1
cable (104-0002-0041-00) can be utilized to pass the video signal to both the SR4
and external recipient.
