Smartgen HMC6 User Manual

HMC6 Power Management Controller User Manual Page 56 of 87
No.
Items
Parameter Range
Default
Description
52.
Set Value
(50-200)%
100
53.
Delay
(0.1-999.9)s
5.0
54.
NEL 2 Trip
Action
(0-1)
0: Disable
1: Enable
1:Enable
External NEL 2 trip is active when the
active power of any busbar genset has
exceeded the set value.
55.
Set Value
(50-200)%
100
56.
Delay
(0.1-999.9)s
8.0
57.
NEL 3 Trip
Action
(0-1)
0: Disable
1: Enable
1:Enable
External NEL 3 trip is active when the
active power of any busbar genset has
exceeded the set value.
58.
Set Value
(50-200)%
100
59.
Delay
(0.1-999.9)s
10.0
60.
NEL 1
Current Trip
Action
(0-1)
0: Disable
1: Enable
1:Enable
External NEL 1 trip is active when
current of any busbar genset has
exceeded the set value.
61.
Set Value
(50-200)%
100
62.
Delay
(0.1-999.9)s
10.0
63.
NEL 2
Current Trip
Action
(0-1)
0: Disable
1: Enable
1:Enable
External NEL 2 trip is active when
current of any busbar genset has
exceeded the set value.
64.
Set Value
(50-200)%
100
65.
Delay
(0.1-999.9)s
8.0
66.
NEL 3
Current Trip
Action
(0-1)
0: Disable
1: Enable
1:Enable
External NEL 3 trip is active when
current of any busbar genset has
exceeded the set value.
67.
Set Value
(50-200)%
100
68.
Delay
(0.1-999.9)s
10.0
69.
Gen Capacity Insufficient
(0.1-999.9)s
1.5
Heavy load request, gen capacity
insufficient judging delay;
70.
Unbalanced
Distribution
of Active
Power
Action
(0-1)
0: Disable
1: Enable
1:Enable
Action when the unbalanced
distribution percentage of active
power is greater than the set value.
71.
Set Value
(0-100)%
20
72.
Delay Value
(0-999.9)s
60.0
73.
Alarm Types
(0-5)
1: Warn
74.
Unbalanced
Distribution
of Reactive
Power
Action
(0-1)
0: Disable
1: Enable
1:Enable
Action when the unbalanced
distribution percentage of reactive
power is greater than the set value.
75.
Set Value
(0-100)%
20
76.
Delay Value
(0-999.9)s
60.0
77.
Alarm Types
(0-5)
1: Warn
78.
Heavy Consumer 1 Analog
(0-1)
0: Disable
Feedback of heavy load 1 obtains the
