-13-
No.EX※※-OMZ0016
Refer to the system configuration example below.
System configuration example
Applicable function
No.
Wireless
Base
Wireless
Remote
Communication
distance
Protocol
Frequency
channel
select function
(F.C.S.)
WEB
function
1 EXW1 EXW1 Up to 100 m V.1.0/V.2.0
*1
Available
*2
-
2 EXW1 EXW1+EX600 *3 V.1.0 NA -
3 EXW1 EX600 Up to 10 m V.1.0 NA -
4 EX600 EXW1 Up to 10 m V.1.0 NA Available
*4
5 EX600 EXW1+EX600 Up to 10 m V.1.0 NA Available
*4
6
*5
EX600
EX600
Up to 10 m
V.1.0
NA
Available
*1: For more details, check the system settings of the Base.
*2: Available in Protocol V.2.0.
*3: Up to 100 m between an EXW1 series Base and Remote, and up to 10 m between an EXW1 series Base
and an EX600-W series Remote.
*4: The settings and monitor function are restricted when communication is established between EX600-
WEN/WPN and EXW1-R*.
*5: This configuration consists solely of EX600-W series units; refer to the operation manual for the product
in use.
○ System configuration example 1
Wireless Base: EXW1-BMJA*
Wireless Remote: EXW1 series
<Wireless Base>
<Wireless Remote>
