Accessories
Accessory List
For the selection of accessories, refer to the catalog.
(1) Assembly type connectors
PCA-1557617 CC-Link communication, Plug
PCA-1557620 CC-Link communication, Socket
(2) Power supply cables
PCA-1564927 Cable with M12 connector, B code, Socket, Straight 2 m, SPEEDCON compatible
PCA-1564930 Cable with M12 connector, B code, Socket, Straight 6 m, SPEEDCON compatible
PCA-1564943 Cable with M12 connector, B code, Socket, Right angle 2 m, SPEEDCON compatible
PCA-1564969 Cable with M12 connector, B code, Socket, Right angle 6 m, SPEEDCON compatible
(3) CC-Link communication cables
PCA-1567720 Cable with M12 connector, A code, Socket, Straight 5 m, SPEEDCON compatible
PCA-1567717 Cable with M12 connector, A code, Plug, Straight 5 m, SPEEDCON compatible
EX9-AC005-SSPS Connectors at both ends, A code, Socket/Plug, Straight 0.5 m, SPEEDCON compatible
EX9-AC010-SSPS Connectors at both ends, A code, Socket/Plug, Straight 1 m, SPEEDCON compatible
EX9-AC020-SSPS Connectors at both ends, A code, Socket/Plug, Straight 2 m, SPEEDCON compatible
EX9-AC030-SSPS Connectors at both ends, A code, Socket/Plug, Straight 3 m, SPEEDCON compatible
EX9-AC050-SSPS Connectors at both ends, A code, Socket/Plug, Straight 5 m, SPEEDCON compatible
EX9-AC100-SSPS Connectors at both ends, A code, Socket/Plug, Straight 10 m, SPEEDCON compatible
EX9-AC005-SAPA Connectors at both ends, A code, Socket/Plug, Right angle 0.5 m, SPEEDCON
compatible
EX9-AC010-SAPA Connectors at both ends, A code, Socket/Plug, Right angle 1 m, SPEEDCON
compatible
EX9-AC020-SAPA Connectors at both ends, A code, Socket/Plug, Right angle 2 m, SPEEDCON
compatible
EX9-AC030-SAPA Connectors at both ends, A code, Socket/Plug, Right angle 3 m, SPEEDCON
compatible
EX9-AC050-SAPA Connectors at both ends, A code, Socket/Plug, Right angle 5 m, SPEEDCON
compatible
EX9-AC100-SAPA Connectors at both ends, A code, Socket/Plug, Right angle 10 m, SPEEDCON
compatible
(4)e-CON
ZS-28-□
e-CON
connector Part
No.
AWG No.
Conductor
cross
sectional area
(mm SQ)
Wire O.D.
(mm)
Color of cover
ZS-28-C-1
24~26 0.14~0.2
ø1.0~ø1.2 Yellow
ZS-28-C-2 ø1.2~ø1.6 Orange
ZS-28-C-3
22~20 0.3~0.5
ø1.0~ø1.2
Green
ZS-28-C-4
ø1.2~ø1.6
Blue
ZS-28-C-5
- 0.1~0.5
ø1.6~ø2.0
Grey
ZS-28-CA-1
ø0.6~ø0.9
Orange
ZS-28-CA-2 ø0.9~ø1.0 Red
ZS-28-CA-3
ø1.0~ø1.15
Yellow
ZS-28-CA-4
ø1.15~ø1.35
Blue
ZS-28-CA-5
ø1.35~ø1.6
Green
