SMC Networks EXW1-BMJA Series User Manual

-97-
No.EX※※-OMZ0016
○EXW1-RDM*
The wireless communication specifications are the same as EXW1-BMJA*.
General specifications
Item
Specification
Enclosure
IP20
Ambient operating temperature
-10 to +50
o
C
Ambient storage temperature
-20 to +60
o
C
Ambient humidity
35 to 85% RH (no condensation)
Withstand voltage
500 VAC 1.0 min. External terminals (including the FE
terminal) and enclosure screws
Insulation resistance
10 MΩ or more 500 VDC External terminals (including the FE
terminal) and enclosure screws
Vibration resistance
EN61131-2 compliant
5≦f<8.4 Hz 3.5 mm
8.4≦f<150 Hz 9.8 m/s2
Impact resistance
EN61131-2 compliant, 147 m/s2, 11 ms
Mounting
Through hole for M4 screw (2 pcs.)
Standards
CE marked
Weight 130 g (body), 100 g (external antenna set)
Electrical specifications
Item
EXW1-RDMP*
EXW1-RDMN*
US1 (for control / input) power
voltage drop
24 VDC +/-10%
US2 (for output) power voltage)
24 VDC +/-10%
Current consumption (US1)
100 mA or less
Input
specificati
on
Number of points
8 points (2 points/connector)
Output type
PNP
NPN
Connector type
e-CON (4 pins)
Max. supply current
for sensor
0.3 A / connector, 1 A / unit
ON current
Typ 0.5 mA
OFF current
2 mA or less
ON voltage
11 V or more
OFF current
5 V or less
Short circuit
protection function
Available
Output
specificati
ons
Number of points
8 points (2 points / connector)
Output type
PNP
NPN
Connector type
e-CON (4 pins)
Maximum load
current
0.3 A / point, 2 A / unit
Short circuit
protection function
Available
