SMC Networks EXW1-BMJA Series User Manual

-75-
No.EX※※-OMZ0016
I/O Mapping Order When EX600-WSV* is Paired
Please note that when EXW1-BMJA* and EX600-WSV* are paired, the mapping order of the EX600 I/O
unit and the valve manifold connected to the Remote is different depending on the I/O unit layout mode in
the Remote parameter setting. Refer to the operation manual of EX600-W Series for details on the I/O unit
mapping order when an EX600-W Series unit is paired.
Mode 1: Mapping to the right from the end plate
Mode 2: Mapping to the left from the wireless unit
I/O and diagnostic mapping examples in mode 1 and mode 2 are shown below.
•The compact wireless Base (EXW1-BMJA*) is in operation mode 2.
•Number of connected units: 15, Bit area RX/RY: 128/128, Word area RWr/RWw: 16/16
<Example 1>
●I/O mapping order Mode 1
Unit 0
Unit 1
Unit 2
Unit 3
End
plate
DY□B
Digital
output
8 bit
Output
AXA
Analog
input
32 bit
input
DX□D
Digital
input
16 bit
input
EX600-WSV*
Remote
32 bit
Output
Valve
manifold
(32 points)
Remote setting parameters values
(Wireless channel 001)
Module input size: 64 points / 64 bits
Module output size: 48 points / 48 bits
Valve manifold output size: 32 points /
32 bits
I/O unit layout mode: Mode 1
Remote configuration (Wireless channel "001")
Input data: [Unit 1] Analog input unit (EX600-AXA): 32 bits occupied
[Unit 2] Digital input unit (EX600-DX*D): 16 bits occupied
Output data: [Unit 0] Digital output unit (EX600-DY*B): 8 bits occupied
[Unit 3] Remote (EX600-WSV*): 32 bits occupied
Unit 0
Unit 1
Unit 2
Unit 3
End
plate
DY□B
Digital
output
8 bit
Output
DX□D
Digital
input
16 bit
input
DX□B
Digital
input
8 bit
input
EX600-WSV*
Remote
0 bit
Output
End
plate
(Output side)
Remote setting parameters values
(Wireless channel 002)
Module input size: 32 points / 32 bits
Module output size: 16 points / 16 bits
Valve manifold output size: 0 points / 0
bits
I/O unit layout mode: Mode 1
Remote configuration (Wireless channel "002")
Input data: [Unit 1] Digital input unit (EX600-DX*D): 16 bits occupied
[Unit 2] Digital input unit (EX600-DX*B): 8 bits occupied
Output data: [Unit 0] Digital output unit (EX600-DY*B): 8 bits occupied
[Unit 3] Remote (EX600-WSV*): 0 bits occupied
