SMC Networks EXW1-BMJA Series User Manual

-94-
No.EX※※-OMZ0016
Specifications Table
○EXW1-BMJA*
CC-Link communication specifications
Item
Specification
Protocol
CC-Link (Ver.1.10, Ver.2.00)
Station type
Remote device
Device type
Wireless equipment (code 0x4B)
Station number
1-64 stations
Communication speed
156 / 625 kbps, 2.5 /5 / 10 Mbps
Setting file
CSP+ file *1
Communication method
Broadcast polling
Occupied area
(Inputs/ outputs)
Max (896 / 896) *2
Maximum number of occupied
stations
4
Supported functions
Cyclic transmission
Extended cyclic transmission
(only when Ver.2.00 is specified)
Longer cable between stations
*1: The setting file can be downloaded from the SMC Web site
*2: Varies depending on the operation mode setting
Electrical specifications
Item
Specification
US1 (for control) power supply
voltage range
24 VDC+/-10 %
Current consumption
100 mA or less
General specifications
Item
Specification
Enclosure
IP67
Ambient operating temperature -10 to +50
o
C
Ambient storage temperature
-20 to +60
o
C
Ambient humidity
35 to 85% RH (no condensation)
Withstand voltage
500 VAC 1.0 min. External terminals (including the FE
terminal) and enclosure screws
Insulation resistance
10 MΩ or more 500 VDC External terminals (including the FE
terminal) and enclosure screws
Vibration resistance
EN61131-2 compliant
5≦f<8.4 Hz 3.5 mm
8.4≦f<150 Hz 9.8 m/s2
Impact resistance
EN61131-2 compliant, 147 m/s2, 11 ms
Mounting Through hole for M4 screw (2 pcs.)
Standards
CE marked
Weight
150 g (body), 100 g (external antenna set)
