SMC Networks EXW1-BMJA Series User Manual

-95-
No.EX※※-OMZ0016
Wireless communication specifications
Item
Specification
Protocol
SMC original protocol (SMC encryption)
Radio wave type (spread)
Frequency Hopping Spread Spectrum (FHSS)
Frequency band
2.4 GHz (2403~2481 MHz)
Frequency channel select function
(F.C.S.)
Supported *1
Frequency channel
Max. 79 ch (Bandwidth: 1.0 MHz)
Communication speed
1 Mbps / 250 kbps *2
Communication distance Up to 100 m line of sight (depending on the environment)
Radio Law certificate
Refer to the official SMC website for the latest information as to
which countries the product is certified.
*1: The number of selectable frequency channels varies depending on the product number.
*2: Select a protocol before performing pairing (V.2.0: 1 Mbps, V.1.0: 250 kbps). Different communication speeds are mutually incompatible.
○EXW1-RDX*
The wireless communication specifications are the same as EXW1-BMJA*.
General specifications
Item
Specification
Enclosure
IP20
Ambient operating temperature
-10 to +50
o
C
Ambient storage temperature
-20 to +60
o
C
Ambient humidity
35 to 85% RH (no condensation)
Withstand voltage
500 VAC 1.0 min. External terminals (including the FE terminal) and
enclosure screws
Insulation resistance
10 MΩ or more 500 VDC External terminals (including the FE
terminal) and enclosure screws
Vibration resistance
EN61131-2 compliant
5≦f<8.4 Hz 3.5 mm
8.4≦f<150 Hz 9.8 m/s2
Impact resistance EN61131-2 compliant, 147 m/s2, 11 ms
Mounting
Through hole for M4 screw (2 pcs.)
Standards
CE marked
Weight
130 g (body), 100 g (external antenna set)
Electrical specifications
Item Specification
US1 (for control / input) power
voltage drop
24 VDC +/-10%
Current consumption
100 mA or less
Input
specificati
on
Number of points
16 points (2 points / connector)
Output type
NPN
Connector type
e-CON (4 pins)
Max. supply current
for sensor
0.3 A / connector, 2 A/unit
ON current
Typ 0.5 mA
OFF current
2 mA or less
ON voltage
11 V or more
OFF current
5 V or less
Short circuit
protection function
Available
