-46-
No.EX※※-OMZ0016
When FCS Setting is clicked, the following screen is displayed.
(1) W-LAN Channel indicators
The W-LAN indicators make it possible to select frequencies corresponding to W-LAN channels at one
time.
* In the example above, W-LAN Channel: CH.10 is selected.
(2) W-CH indicators
The W-CH indicators make it possible to select frequencies for each CH.
* In the example above, frequencies 2419, 2426-2428, and 2446-2468 [MHz] are unused Channels.
Note that frequencies 2446-2468 [MHz] correspond to (1) W-LAN Channel: CH.10 above.
•Indicator colours
Green
Selected W-LAN channel (W-LAN Channel area)
Active frequency channel (W-CH area)
Yellow Advertise channel
Cannot be set for inactive frequency
channels
Inactive frequency channel
•If advertise channels are included in the CH at the time of selecting a W-LAN Channel, they cannot
be selected. To select them, initialize the product or remove all the registered Remotes and then
configure F.C.S. before performing pairing.
•To use 5-7 frequency channels, neighboring frequencies need to be separated by 3 MHz.
•To use 8-14 frequency channels, neighboring frequencies need to be separated by 2 MHz.
•To use 15 frequency channels or more, neighboring frequencies can be selected.
To Next Page
