-63-
No.EX※※-OMZ0016
Problem
No.
LED
name
LED status
Possible causes Investigation and countermeasures
Colour
of LED
ON/Flashing
4 W-SS
Red Flashing
When Protocol V.1.0 is used
(1) Remote power supply is
OFF
(2) Outside the wireless
coverage area
(1) Supply 24 VDC +/-10% to the US1 (for
control / input) power source of the
Remote.
(2) The distance which wireless
communication between wireless systems
can be established may have been
exceeded. Reconsider the operating
environment, such as the installation
conditions, of the Base and Remote.
Orange Flashing
When Protocol V.2.0 is used
(1) Remote power supply is
OFF
(2) Outside the wireless
coverage area
(1) Supply 24 VDC +/-10% to the US1 (for
control / input) power source of the
Remote.
(2) The distance which wireless
communication between wireless systems
can be established may have been
exceeded. Reconsider the operating
environment, such as the installation
conditions, of the Base and Remote.
- OFF Remote not registered
Check the registration status of the Remote
and perform pairing correctly.
5 W-NS
Green Flashing
(1) Some Remotes are not
connected
(2) Some registered
Remotes have no
wireless signal
(1) Supply 24 VDC +/-10% to the US1 (for
control / input) power source of the
Remote.
(2) The distance which wireless
communication between wireless systems
can be established may have been
exceeded. Reconsider the operating
environment, such as the installation
conditions, of the Base and Remote.
Red Flashing
(1) Power supply to all
registered Remotes is
OFF
(2) All registered Remotes
have no wireless signal
(1) Supply 24 VDC +/-10% to the US1 (for
control / input) power source of the
Remote.
(2) The distance which wireless
communication between wireless systems
can be established may have been
exceeded. Reconsider the operating
environment, such as the installation
conditions, of the Base and Remote.
Red ON
No Remotes are connected
due to a failure of the Base
Replace the Base. If the error persists after
replacement, stop using the equipment and
contact your SMC sales representative.
Re
d
Gr
ee
n
Alternate
Flashing
In pairing mode.
The system has been set to "Pairing enable".
Change the setting to "Pairing disable" when
pairing is not conducted.
- OFF Remote not registered
Check the registration status of the wireless
unit and conduct pairing with the Remote
correctly.
