SMC Networks EXW1-BMJA Series User Manual

-77-
No.EX※※-OMZ0016
<Example 2>
●I/O mapping order Mode 2
Unit 3
Unit 2
Unit 1
Unit 0
End
plate
DY□B
Digital
output
8 bit
output
AXA
Analog
input
32 bit
input
DX□D
Digital
input
16 bit
input
EX600-WSV*
Remote
32 bit
output
Valve
manifold
(32 points)
Remote setting parameters values
(Wireless channel 001)
Module input size: 64 points / 64 bits
Module output size: 48 points / 48 bits
Manifold output size: 32 points / 32 bits
I/O unit layout mode: Mode 2
Remote configuration (Wireless channel "001")
Input data: [Unit 1] Digital input unit (EX600-DX*D): 16 bits occupied
[Unit 2] Analog input unit (EX600-AXA): 32 bits occupied
Output data: [Unit 0] Remote (EX600-WSV*): 32 bits occupied
[Unit 3] Digital output unit (EX600-DY*B): 8 bits occupied
Unit 3
Unit 2
Unit 1
Unit 0
End
plate
DY□B
Digital
output
8 bit
output
DX□D
Digital
input
16 bit
input
DX□B
Digital
input
8 bit
input
EX600-WSV*
Remote
0 bit
output
End
plate
(Output side)
Remote setting parameters values
(Wireless channel 002)
Module input size: 32 points / 32 bits
Module output size: 16 points / 16 bits
Valve manifold output size: 0 points / 0
bits
I/O unit layout mode: Mode 2
Remote configuration (Wireless channel "002")
Input data: [Unit 1] Digital input unit (EX600-DX*B): 8 bits occupied
[Unit 2] Digital input unit (EX600-DX*D): 16 bits occupied
Output data: [Unit 0] Remote (EX600-WSV*): 0 bits occupied
[Unit 3] Digital output unit (EX600-DY*B): 8 bits occupied
I/O mapping order Mode 2: I/O map
RX/RY
Input data
Output data
Module name
Unit name
Module name
Unit name
Byte0
Remote
Wireless channel "001"
DX*D (Unit 1)
Remote
Wireless channel "001"
EX600-WSV* (Unit 0)
32 valve outputs
Byte1
Byte2
AXA (Unit 2)
Byte3
Byte4
DY*B (Unit 3)
Byte5
Reserved
Byte6
Reserved
Remote
Wireless channel "002"
DY*B (Unit 3)
Byte7
Reserved
Reserved
Byte8
Remote
Wireless channel "002"
DX*B (Unit 1)
Reserved
Byte9
DX*D (Unit 2)
Reserved
Byte10
Reserved
Byte11
Reserved
Reserved
Byte12
Reserved
Reserved
Byte13
Reserved
Reserved
Byte14
Reserved (system area)
Reserved (system area)
Byte15
Reserved (system area)
Reserved (system area)
Total
16 bytes
16 bytes
