SMC Networks EXW1-BMJA Series User Manual

-82-
No.EX※※-OMZ0016
<Example 2>
●Mode 2
Unit 2
Unit 1
Unit 0
End
plate
DY□B
Digital
output
1 byte
output
DX□D
Digital
input
2 byte
input
EX600-WEN*
Base
2 byte
output
Valve
manifold
(16 points)
Base setting parameters values
Diagnostic mapping: None / Simple / Detailed
I/O mapping: Auto
Module input size: 32 points / 4 bytes
Module output size: 32 points / 4 bytes
Valve manifold output size:
16 points / 2 bytes
I/O unit layout mode: Mode 2
Number of registered Remotes: 15
Base configuration
Input data: [Unit 1] Digital input unit (EX600-DY*D): 2 bytes occupied
Output data: [Unit 0] Base (EX600-WEN*): 2 bytes occupied
[Unit 2] Digital output unit (EX600-DY*B): 1 byte occupied
EXW1-RDX*
Digital input
2 byte
Remote setting parameters values
(Wireless channel 001)
Module input size: 16 points / 2 bytes
Module output size: 0 points / 0 bytes
Remote configuration (Wireless channel "001")
Input data: EXW1-RDX* 2 bytes occupied
EXW1-RDY*
Digital output
2 byte
Remote setting parameters values
(Wireless channel 002)
Module input size: 0 points / 0 bytes
Module output size: 16 points / 2 bytes
Remote configuration (Wireless channel "001")
Output data: EXW1- RDY* 2 bytes occupied
EXW1-RDM*
Digital input/output
Input/output 2 bytes
each
Remote setting parameters values
(Wireless channel 003)
Module input size: 16 points / 2 bytes
Module output size: 16 points / 2 bytes
Remote configuration (Wireless channel "003")
Input data: EXW1-RDM* 2 bytes occupied
Output data: EXW1-RDM* 2 bytes occupied
* The number of inputs and outputs of EXW1-RDM* is fixed at 16 (16 bits), and
only the lower 8 bits are valid.
