HRSH Series 8.4 Cooling Capacity
8-13
8.4 Cooling Capacity
8.4.1 HRSH100-A-20/40-
Fig. 8-7: Cooling Capacity (HRSH100-A-20/40-)
8.4.2 HRSH150-A-20/40-
Fig. 8-8: Cooling Capacity (HRSH150-A-20/40-)
0
5
10
15
20
25
5 10 15 20 25 30 35
Circulating fluid temperature [
o
C]
Cooling capacity [kW]
0
2
4
6
8
10
12
14
5 10 15 20 25 30 35
Circulating fluid temperature [
o
C]
Cooling capacity [kW]
Ambient temperature: 32
o
C
Ambient temperature: 43
o
C
Ambient temperature: 45
o
C
Ambient temperature: 32
o
C
Ambient temperature: 43
o
C
Ambient temperature: 45
o
C
