SMC Networks HRSH100-A 20 Series User Manual

HRX-OM-Q026
Chapter 3 Transport and Setting Up
HRSH Series 3.1 Transport
3-3
3.1.2 Transportation using casters
In case of purchasing option A or the optional accessories, “Caster Adjuster-
foot kit” (HRS-KS001/KS002) separately and after fastening it to the product.
Fig. 3-2 Transportation using casters (This drawing shows “HRSH250-A-20”.)
Each swivel caster can rotate 360
degrees freely.
Swivel
caster
Raise the
adjuster foot.
Raise the adjuster feet and push the corners of the product when
moving the product using the casters.
Do not hold the piping connections or handles of the panels when
moving by casters, or it may cause damage to the product..
This is a heavy product. (Refer to Table 3-1 Weight of the product).
Moving the product by casters should be done by 2 persons or more.
