8.6 Types of Hazard Labels (HRSH***-**-40-**,HRSH***-**-20-S) HRSH Series
8-20
8.6 Types of Hazard Labels (HRSH***-**-40-
**,HRSH***-**-20-S)
To ensure the safety of the operators, potential hazards are classified and
marked with warning labels.
Read this section before starting any work on the product.
◼ Electric shock warning
◼ High temperature warning
◼ Rotating objects warning (Air-cooled type only)
◼ Warning related to those other than shown above (HRSH--20-S only)
This symbol stands for danger of electric shock.
The product has some uncovered terminals applied with high voltage
inside.
⚫ Do NOT operate the product without the cover panels mounted.
⚫ Do NOT work on the parts inside the product unless you have
been trained for the product service.
⚫ Do NOT work inside this product unless you have been trained to
This symbol stands for danger of burns.
The product has surfaces that can reach high temperatures during
operation. Even after the power is turned off, there can still be
residual heat in the product., which causes burns.
⚫ Do NOT operate the product without cover panels fitted.
⚫ Do NOT start working on the parts inside the product until the
temperature has decreased sufficiently.
This symbol stands for a danger of your fingers/hand being cut or
getting caught by the rotating objects.
⚫
The product contains a cooling fan that rotates during operation of
the product (for air-cooled type).
The fan may stop and restart intermittently during operation.
Do NOT operate the product without the cover panels mounted.
⚫
This symbol stands for a multiplex danger.
Electric shock: The product has some uncovered terminals applied
with high voltage.
Rotary fan: This product has a rotating object inside the cover panel.
<Water-cooled refrigerated type>
High pressure inside: This product contains high pressure liquid in the
piping and the tank.
- Do not operate the product without the cover panels mounted.
